Fuel Oil/Gas Steam Cleaner
This product converts thermal energy produced by burning diesel fuel to steam, without the need of high-load power, and ordinary household socket or equipped small generator could provide power. This project is to use super steam cleaning machine to clean objects through high-temperature and high-pressure steam. Because the steam has features of high temperature and high pressure, it has an advantage that other cleaning methods are beyond comparison, and is a revolution for cleaning industry. This steam cleaning machine has a convenient operation, and is equipped with steam cleaning pipe and cleaning gun. Generally, it could enter continuous cleaning work only by powering on and supplying water. Steam cleaning has no damage to the equipment, no secondary pollution, and at the same time has effect of high temperature sterilization etc.
Feature of Fuel Oil/Gas Steam Cleaner
1. For different cleaning objects and dirt, high-efficiency cleaning of dirt meets the requirements of different customers in different industries. It changes the pollution of traditional cleaning process on the environment.
2. Clean the equipment without damage, and improve the service life of equipment;
3. The steam does not produce any dirt or secondary pollution;
4. It has effect of high-temperature sterilization in food and pharmaceutical industries.
Specification of Fuel Oil/Gas Steam Cleaner
| Model | LSS0.035 | LSS0.05 | LSS0.1 | LSS0.2 | LSS0.3 | LSS0.5 | |
| Evaporation(kg/h) | 35 | 50 | 100 | 200 | 300 | 500 | |
| Thermal efficiency(%) | ≥90 | ≥90 | ≥93 | ≥93 | ≥93 | ≥93 | |
| Rated pressure(bar) | 7 | 7 | 8 | 8 | 8 | 8 | |
| Steam temperature(℃) | 170 | 170 | 175 | 175 | 175 | 175 | |
| Fuel | 0# Diesel(kg/h) | 2.2 | 3.2 | 6.1 | 12.2 | 18.3 | 30.5 |
| Coal gas(Nm3/h) | 6.2 | 8.9 | 17 | 34 | 51 | 85 | |
| Natural gas(Nm3/h) | 2.8 | 4 | 7.6 | 15.2 | 22.8 | 38 | |
| Liquefied gas(kg/h) | 2.25 | 3.3 | 5.7 | 11.4 | 17.1 | 28.5 | |
| Dimension | L(mm) | 800 | 800 | 900 | 1000 | 1150 | 1350 |
| W(mm) | 800 | 800 | 900 | 1000 | 1150 | 1350 | |
| H(mm) | 1350 | 1400 | 1700 | 2100 | 2400 | 2650 | |
| Number of nozzle(pc) | 2 | 2 | 4 | 4 | 4 | 4 | |
| Circular nozzle(mm) | Φ6 | Φ6 | Φ6 | Φ6 | Φ6 | Φ6 | |
| Square nozzle(mm) | 3 x 8 | 3 x 8 | 3 x 8 | 3 x 8 | 3 x 8 | 3 x 8 | |
| The barrel length(m) | 8~20 | 8~20 | 8~20 | 8~20 | 8~20 | 8~20 | |
| Weight(kg) | 240 | 250 | 550 | 850 | 1100 | 1300 | |
